Favourite FVT LittleBee 20A PRO ESC - RC Papa

Favourite FVT LittleBee 20A PRO ESC

** Genuine Product , not Clone **

** In Stock now **


One of the most 'Favorite' ESC's finally got an upgrade! With this ESC's brand new F396 MCU processor, it is able to handle the higher RPM motors with ease. The processor on this ESC runs nearly twice as fast as the previous version, nearly 50Mhz. It has also been equipped with a bit more flash memory and RAM. Designed to be compact and lightweight, this may be the perfect choice for many of the FPV Racers and Acro flyers! Thrust results to come. One of the smallest ESC's on the market for its size but can keep up with the bigger brother's. FVT LITTLEBEE 20A PRO ESC's supports 2-4s lipo's, are mosfet driven and with fast, dedicated driver chips on a high quality PCB.

Turn on Dampen Light in BLHeli and enable the oneshot 125 capabilities of braking and faster response. Driven by a Silabs processor and gate-drivers making the motor braking especially fast.

These are OPTO ESCs - this means that you will need your own 5 volt BEC to power your flight controller.

Features :

BLHeli Factory Firmware

Silabs MCU

DLM and Oneshot Capable

Signal wire programmable with: wire Cleanflight/Betaflight or LittleBee USB Linker

Specs :

Input: 2-4s Lipo

Constant: 20 Amps

Burst: 30 Amps(10 seconds)

Weight: 6g w/wires

Dimensions: 24.5 x 12.5 x 3mm

Motor wire: 50mm 20g

Signal wire: 100mm 22g

MCU: Silabs F396 @ 48Mhz

PCB - 4 Layer Blind Pole PCB - 3oz Pour

Mosfet: N-Channel

BEC: None
